Dalsan PUNTO Turkey (Dalsan Production Lines) SKU: 170.TC.060.50.27.300 TS EN 14195

Dalsan PUNTO TC & TU Suspended Ceiling Profiles (CD 60 / UD 28)

Cold-formed galvanized steel ceiling channels: TC 60 acts as primary and secondary suspension runners; TU 28 provides wall perimeter support.

Dalsan PUNTO TC & TU Suspended Ceiling Profiles (CD 60 / UD 28)
Zoom
REQUEST EXPORT QUOTE Request Sample Box (Express) Technical Specifications
Standard / Norm
TS EN 14195
Thicknesses / Gauges
0.40 mm, 0.45 mm
Reaction to Fire
Euroclass A1
Export Packing
Strapped & Hooded
40ft HC Container Load
24 - 25 Metric Tons
Lead Time (Ex-Works)
7 - 10 Days
Direct Factory Supply: All dispatches are strictly full truckload (FTL), container (FCL), and major project based. No retail sales.
B2B Wholesale Only / No Retail
HS Tariff Schedule Code
7216.61.10.00.00
Loading Seaports (POL)
Mersin (MIP) / Evyap / Izmir
Supported Incoterms
FOB / CIF / CFR / DAP / EXW
Export Documents
EUR.1 / A.TR / COO / CE DoP
Section 01 • Product Overview
Dalsan PUNTO TC & TU Suspended Ceiling Profiles (CD 60 / UD 28)
Zoom
Authentic Factory Product Dalsan PUNTO

Technical Overview & Manufacturing Quality

Cold-formed galvanized steel ceiling channels: TC 60 acts as primary and secondary suspension runners; TU 28 provides wall perimeter support.

Manufactured in modern automated facilities in Turkey under stringent European standards. Every production batch undergoes rigorous laboratory testing for flexural breaking load, dimensional tolerances, core cohesion under fire, and surface water absorption. (TS EN 14195).

Manufacturing Standards
CE Marking & Declaration of Performance (DoP)
ISO 9001:2015 Quality Management Certified
Full Compliance with Harmonized EN Standards
Export Ready ISPM 15 Treated Pallet Packaging
Section 02 • Engineering Specifications

PUNTO TC / TU Suspended Ceiling & Perimeter Profiles Specifications

Official factory product codes, cross-section dimensions, unit weights, and production dispatch plants.

EN 14195 & DIN 18182-1
Loading Facilities & Seaport Terminals:
Ankara (Bala) Gebze (Ist) Turgutlu (Izm)
TC profile (27 x 27) 0,50 mm 170.TC.060.50.27.300
0,45 kg / m
Cross-Section Dimensions 27 x 60 x 27 mm
Standard Lengths 3,0 m
Packaging / Bundle 12 pcs / bundle
Loading Facilities: Ankara Gebze Turgutlu
TC profile (27 x 27) 0,60 mm 170.TC.060.60.27.300
0,55 kg / m
Cross-Section Dimensions 27 x 60 x 27 mm
Standard Lengths 3,0 m
Packaging / Bundle 12 pcs / bundle
Loading Facilities: Ankara Gebze Turgutlu
TU profile (27 x 27) 0,50 mm 170.TU.028.50.27.300
0,29 kg / m
Cross-Section Dimensions 27 x 28 x 27 mm
Standard Lengths 3,0 m
Packaging / Bundle 12 pcs / bundle
Loading Facilities: Ankara Gebze Turgutlu
TU profile (24 x 24) 0,50 mm 170.TU.028.50.24.300
0,27 kg / m
Cross-Section Dimensions 24 x 28 x 24 mm
Standard Lengths 3,0 m
Packaging / Bundle 12 pcs / bundle
Loading Facilities: Ankara Gebze Turgutlu
TU profile (27 x 27) 0,60 mm 170.TU.028.60.27.300
0,29 kg / m
Cross-Section Dimensions 27 x 28 x 27 mm
Standard Lengths 3,0 m
Packaging / Bundle 12 pcs / bundle
Loading Facilities: Ankara Gebze Turgutlu
TU profile (20 x 20) 172.TU.028.00.20.300
0,18 kg / m
Cross-Section Dimensions 20 x 28 x 20 mm
Standard Lengths 3,0 m
Packaging / Bundle 12 pcs / bundle
Loading Facilities: Ankara Gebze Turgutlu

Factory Dispatch Facilities & Export Seaport Connections

All orders are dispatched from the geographically most advantageous manufacturing facility based on delivery terms (FOB, CFR, CIF, DAP) and destination country:

Golbasi - Bala Plant (Ankara)
Active Dispatch
Port of Mersin (MIP)
Middle East, Red Sea, North Africa, Arabian Gulf
Gebze Plant (Kocaeli)
Active Dispatch
Ports of Istanbul (Ambarli & Diliskelesi)
Black Sea, West Mediterranean, European Road Freight
Turgutlu Plant (Manisa)
Active Dispatch
Ports of Izmir (Alsancak & Nemport)
Aegean Sea, Greece, Italy, Adriatic & Balkans
Elmadag Plant (Ankara)
Port of Mersin (MIP) & Road Freight
Central Anatolia, Caucasus & Middle East Corridor
Cerkezkoy Plant (Tekirdag)
Port of Asyaport & Europe Border Gate
Balkans, Central Europe & Northern Sea Routes
Container pallet nesting configurations, ocean freight rates and transit times: Export Logistics & Container Guide →
Direct Export Sales Desk

Request Proforma Quote (FOB / CIF)

Get factory-direct pricing and container loading plans within 2 hours.

Direct manufacturer & mill supply (no intermediate markups)
CE Marking, Declaration of Performance (DoP) & ISO 9001
Flexible payment: T/T and 100% Confirmed Irrevocable L/C accepted
SEND INQUIRY VIA WHATSAPP
Need Help Calculating Quantities?

Use our engineering calculator to estimate exact board count, studs, tracks, and screws.

Launch BOQ Estimator
Section 03 • Architectural Applications

Recommended Project Uses & Systems

Concealed grid drywall suspended ceiling frameworks
Direct ceiling linings and acoustic ceiling baffles
Curved ceiling bulkheads and lighting coves
Section 04 • Export Packaging & Logistics

Pallet Stacking & 40ft HC Container Payload

40ft HC Container: Approx. 24,000 - 26,000 Linear Meters.

Standard Pallet Dimensions & Packaging Values:
TC 60
12 Pcs / Bundle (3.0m)
TU 28
24 Pcs / Bundle (3.0m)
Export Moisture Barrier Guarantee: All sea freight pallets are placed on ISPM 15 treated wooden blocks, cross-strapped with polyester tension bands, protected with corrugated corner guards, and encapsulated in heat-shrunk polyethylene weather hoods to safeguard against maritime humidity.
